DRI424730L

In stock

D-SERIES DRI, Relay, Number of contacts: 2, CO contact AgSnO, Rated control voltage: 230 V AC, Continuous current: 5 A, Flat blade connections (2.5 mm x 0.5 mm), Test button available: No

Item No.7760056334

Product details

Approvals

Approvals
ROHS	Conform
UL File Number Search	UL Website
Certificate no. (cULus)	E312083

General ordering data

Version	D-SERIES DRI, Relay, Number of contacts: 2, CO contact AgSnO, Rated control voltage: 230 V AC, Continuous current: 5 A, Flat blade connections (2.5 mm x 0.5 mm), Test button available: No
Order No.	7760056334
Type	DRI424730L
GTIN (EAN)	6944169739811
Qty.	20 items

Dimensions and weights

Depth	28 mm
Depth (inches)	1.102 inch
Height	31 mm
Height (inches)	1.22 inch
Width	13 mm
Width (inches)	0.512 inch
Net weight	18.832 g

Temperatures

Storage temperature	-40 °C…85 °C
Ambient temperature	-40 °C…55 °C
Humidity	35…85 % rel. humidity, no condensation

DRI424730L
